Industrial process pressure control
Aerospace fields
Petroleum and chemical industry
Instrument,medical treatment,food and other industries
Marine and shipbuilding industries
Water conservancy, water and electricity, power plant furnace draft, and other industries
Laser trimming resistor, temperature compensation, wide temperature use
Import diffusion silicon or ceramic chip, suitable for different pressure measurement
Overload shock resistance and strong interference resistance ability
Excellent corrosion resistance, can measure a variety of media
Over-voltage over-current reverse polarity circuit protection, high reliability
High IP grade
Anti surge voltage, reverse polarity protection
Safe explosion-proof certification
| Power supply | DC 24V（12V～32V） |
| Load capacity | current mode≤500Ω (DC24V) |
| accuracy class | grade 0.2 (range from 70kPa to 5MPa ) |
| grade 0.5(range from 5kPa to 70kPa; 5 MPa to 35 MPa) | |
| medium temperature | － 20℃～+60℃ |
| environment temperature | － 20℃～+60℃ |
| Response time | ≤ 50ms |
| Hysteresis and repeatability | ± 0.1％F.S |
| long-term stability | ± 0.1％F.S/y |
| nonlinear | ± 0.2％F.S |
| Thermal zero drift | ± 0.02％F.S/℃ |
| Over load pressure | two times of range |
| electrical connection | terminal |
| process connection | M20 × 1.5 outside thread/DN25 flange connect/others |
| The external parts material | Ordinary stainless steel/316stainless steel |
| Shell material | Ordinary stainless steel/316stainless steel/cast aluminum shell |
| IP grade | IP 65 |
| Intrinsic safetyexplosive protection | ExibⅡ CT6 matched with safety barrier FBE,FB-A |
| Measuring medium | oil, water, gas and other compatible with 316 stainless steel medium |
| Weight | about 1150g |
